Mobile Equipment	Use	Features
Epiroc M2D Development Drill (Jumbo)	Used to drill holes for developing mining tunnels underground.	Weighs 24 tonnes Powered by 2 x 75KW electric motors 14.3 m long, 2.3m wide and 3.2m high
Epiroc E7C Production Drill (Simba)	Used to drill holes underground which are then loaded with explosives and fired.	Weighs 31.5 tonnes. 13.2 m long, 2.5 m wide and 3.1 m high. Powered by a 2 x 55KW electric motor. Drills holes 89 – 250 mm wide (so typically used for production drilling on undercut level)
Caterpillar R3000H Loader (production)	Used to move production blasted rock from the underground cave to the crusher.	Weighs 55.5 tonnes (75 tonnes loaded). Carries 20 tonnes. Powered by a 409HP diesel engine. 11.5 m long, 3.5 m wide and 3 m high. Maximum speed 37 km/h.
Epiroc ST18 loader	Used as an automated loader to move production blasted rock from the underground cave to the crusher.	Weighs 56.8 tonnes Carries 21 tonnes Powered by a 475 hp diesel engine 11.2m long, 3.1 m wide and 2.8 m high Maximum speed 27 km/h
Sandvik LH621 loader (prepping and development)	Used to move development blasted rock and load haul trucks.	Weighs 56.8 tonnes Carries 21 tonnes Powered by a 475 hp diesel engine 12m long, 3.25 m wide and 2.4 m high Maximum speed 25.5 km/h
Sandvik TH663i Haul Truck	Used to move development blasted rock and load haul trucks.	Weighs 48.4 tonnes Carries 63 tonnes Power by a 760 HP diesel engine 11.5m long, 3.5m wide, 3.45m high Maximum speed 33 km/h (empty)
Caterpillar 992K Wheel Loader	Used for loading haul trucks	Weighs 97 tonnes Bucket capacity of 21 tonnes 5.8 m long and 5.6 m high Maximum speed 24 km/h
Caterpillar 12M Motor Grader	Used for grading roads.	Weighs 18.4 tonnes Blade width 3.7 m 6 cylinder engine with 182 hp Maximum speed 46 km/h
Caterpillar 793C Haul Truck	Used to transport rock to the crusher or waste rock dumps.	Carrying capacity of 240 tonnes and weigh 160 tonnes empty Powered by a 16 cylinder engine producing 2,337 hp 6.5 m high, 7.5 m wide and 12.9 m long Maximum speed 52 km/h
Caterpillar 336 Hydraulic Excavator	Used for loading haul trucks for civil and project works.	Weighs 37.2 tonnes Swing speed 8.75 RPM Maximum travel speed 4.7km/h
Volvo L120F IT (Integrated Tool Carrier)	Used to carry supplies, install vent bags, services, cable bolts and cleaning sumps.	Weighs 20 tonnes Powered by a 223 hp engine
Komatsu WA1200 Loader	Used for loading haul trucks	Bucket capacity of 37 tonnes and weigh 208 tonnes Powered by a 1560 hp motor Production rate of 3,500 tonnes per hour

Mobile Equipment


Use

Features

Epiroc M2D Development Drill (Jumbo)

Used to drill holes for developing mining tunnels underground.

Weighs 24 tonnes
Powered by 2 x 75KW electric motors
14.3 m long, 2.3m wide and 3.2m high

Epiroc E7C Production Drill (Simba)

Used to drill holes underground which are then loaded with explosives and fired.

Weighs 31.5 tonnes.
13.2 m long, 2.5 m wide and 3.1 m high.
Powered by a 2 x 55KW electric motor.
Drills holes 89 – 250 mm wide (so typically used for production drilling on undercut level)

Caterpillar R3000H Loader (production)

Used to move production blasted rock from the underground cave to the crusher.

Weighs 55.5 tonnes (75 tonnes loaded).
Carries 20 tonnes.
Powered by a 409HP diesel engine.
11.5 m long, 3.5 m wide and 3 m high.
Maximum speed 37 km/h.

Epiroc ST18 loader

Used as an automated loader to move production blasted rock from the underground cave to the crusher.

Weighs 56.8 tonnes
Carries 21 tonnes
Powered by a 475 hp diesel engine
11.2m long, 3.1 m wide and 2.8 m high
Maximum speed 27 km/h

Sandvik LH621 loader (prepping and development)

Used to move development blasted rock and load haul trucks.

Weighs 56.8 tonnes
Carries 21 tonnes
Powered by a 475 hp diesel engine
12m long, 3.25 m wide and 2.4 m high
Maximum speed 25.5 km/h

Sandvik TH663i Haul Truck

Used to move development blasted rock and load haul trucks.

Weighs 48.4 tonnes
Carries 63 tonnes
Power by a 760 HP diesel engine
11.5m long, 3.5m wide, 3.45m high
Maximum speed 33 km/h (empty)

Caterpillar 992K Wheel Loader

Used for loading haul trucks

Weighs 97 tonnes
Bucket capacity of 21 tonnes
5.8 m long and 5.6 m high
Maximum speed 24 km/h

Caterpillar 12M Motor Grader

Used for grading roads.

Weighs 18.4 tonnes
Blade width 3.7 m
6 cylinder engine with 182 hp
Maximum speed 46 km/h

Caterpillar 793C Haul Truck

Used to transport rock to the crusher or waste rock dumps.

Carrying capacity of 240 tonnes and weigh 160 tonnes empty
Powered by a 16 cylinder engine producing 2,337 hp
6.5 m high, 7.5 m wide and 12.9 m long
Maximum speed 52 km/h

Caterpillar 336 Hydraulic Excavator

Used for loading haul trucks for civil and project works.

Weighs 37.2 tonnes
Swing speed 8.75 RPM
Maximum travel speed 4.7km/h

Volvo L120F IT (Integrated Tool Carrier)

Used to carry supplies, install vent bags, services, cable bolts and cleaning sumps.

Weighs 20 tonnes
Powered by a 223 hp engine

Komatsu WA1200 Loader

Used for loading haul trucks

Bucket capacity of 37 tonnes and weigh 208 tonnes
Powered by a 1560 hp motor
Production rate of 3,500 tonnes per hour
